Colloidal Silver, Liquid and Extender

Colloidal Silver Liquid is a fast air-drying formulation on basis of 1-Methoxy-2-propanol used to convert a variety of electrically and thermally non-conductive surfaces to conductive surfaces for many applications. The Silver Liquid has an average grain size of less than 1 µm and a silver content of 60%. A brush attached to the cap is included.
Grouped product items
Product Name Qty
Colloidal Silver Liquid, 15g

E12630

€101.60 €120.90
Silver Colloidal Extender, 25ml

E12641

€20.00 €23.80

Product Details

Description

This unique air-drying formulation is used to convert a variety of electrically and thermally non-conductive surfaces to conductive surfaces for many applications. These silver liquids may be utilized during circuit repair processes or as RF shielding materials.

During the application process (the product can be brushed, sprayed or dipped), the material will harden immediately as the solvent begins to evaporate.

The Silver Liquid will harden rapidly when the solvent evaporates. This is sufficient for most applications. For optimal results across electrical and mechanical applications we suggest curing at room temperature for approximately 16-20 hours or at 120-200°C for 30 minutes.

The use of a heat gun is recommended to facilitate curing. Depending on the application of choice additional layers of silver liquid can be applied in order to reach increased levels of conductivity.



Key Properties

  • Comes with brush applicator
  • Adheres to a variety of surfaces: polymer (phenolic) boards, glasses, metals, ceramics, fiberglass, and many plastics
  • Preparation of surfaces prior to application is optional
  • Resistant to solvents
  • Cures at room temperature or at higher temperatures
  • Electrically and thermally conductive
  • Store cool and dry
  • Shake before use



Specifications

Solid components Silver 60% ± 1%
Sheet Resistance 0.02 - 0.05 ohms/sq/mil
Shelf life 6 months. Jar rolling at 1-6 rev/h recommended. Avoid exposure to extreme temperatures.
Storage Store in a dry location at 5-30°C. Allow paint to reach room temperature prior to use. Mix thoroughly before using.

More Information

More Information
Symbol GHS
GHS02 GHS02
GHS07 GHS07
GHS08 GHS08
Signal word
Danger
Mandatory sign
Tightly sealed goggles Tightly sealed goggles
Protective gloves Protective gloves
Hazard statements
H225
H226
H260
H302
H315
H331
H336
H361d
H373
Precautionary statements
P210
P223
P241
P261
P231_232
P303_361_353
P405
P501
Storage Temperature
RT
Shipping Class
Hazardous Good LQ
SDS (multilingual) E12630, E12641
