DiATOME Static Line II Ionizer
The DiATOME Static Line II Ionizer is an antistatic device for ultramicrotomy, which emits negative and positive ions neutralizing the electrostatic charging. The Static Line II ionizer improves handling for trimming, sectioning and section collection at room temperature and is essential for use under cryo conditions.
Product Details
Description
The Static Line II Ionizer prevents that sections stick to the knife-edge, piling up or flying away during section collection. It facilitates the formation of nice ribbons over the knife surface and the pickup of the sections.
Common applications
- Sucrose protected specimens
- Cell cultures in elatine/ sucrose
- Frozen hydrated specimens
- Dry cut Lowicryls at room temperature
- Cryo sectioning of polymers and rubber
Technical data
Voltage: | 230 V |
Nominal frequency: | 50-60Hz |
Nominal output voltage: | approx. 7-8 kV variable |
Power consumption: | approx. 50 VA |
Short circuit output current: | max. 3 mA |
Dimensions: | Length 173 mm Width 113 mm Height 110 mm |
Weight: approx. | 3.5 kg |
More Information
Downloads
(Size: 1.2 MB)
-
