Epofix- Set, 1l Resin, 130ml Hardener and accessory

ST1232

Slow-curing transparent epoxy, particularly suited for vacuum impregnation and mounting very delicate specimens. By adding Epodye (a fluorescent dye), the identification of pores and cracks is made very easy.
€215.70 €256.68

Product Details

Description

Especially formulated for Material Science

Epo-Fix is an old product that has existed only in the metallographic field until now. After extensive testing in our labs we have found that it is a perfect embedding media for a majority of material specimens.


Until now, LR White has been the most commonly used embedding media for materials due to the block hardness it offered, but there are difficulties associated with LR White. For instance, the adherence to the specimen is poor and additives are required to improve its adherence. Another major problem is the inability to orient the specimen correctly in order to cut you block afterwards. This is due to the fact that LR White needs to be oxygen starved and gelatin capsules (vertical) are recommended by the manufacturer for use. Another problem is that polymerization time in the oven can take over 24 hours.

Epo-Fix remedies all of these problems. It has very good sectioning properties, good adherence to the sample, very low viscosity, easy curing in molds (no orientation problems), and quick cure times.

Epo-Fix Technical Data:
A two component epoxy resin, characterized by negligible shrinkage during curing and good mechanical properties in its hardened state. It is particularly suited for embedding hard samples of complicated shape and for vacuum impregnation. Samples such as paper, silicon, ceramics, metals, wafers, and chips are suitable to be used with Epo-Fix. It has low viscosity, low vapour pressure, good wetting properties, and minimal shrinkage. It hardens at room temperature without significant generation of heat in approximately 8 hours (no damage from heat or pressure), and at increased temperatures, 60°C, the hardening time is reduced to 2 hours. It should be noted that if you place Epo-Fix in a desiccator during curing you will eliminate any air bubbles.

More Information

More Information
Application
SEM
Base
Epoxy
Mandatory sign
Tightly sealed goggles Tightly sealed goggles
Protective gloves Protective gloves
Signal word
Danger
Symbol GHS
GHS05 GHS05
GHS07 GHS07
GHS09 GHS09
Hazard statements
H315
H317
H312
H314
H319
H412
Precautionary statements
P261
P305_351_338
P310
P321
P405
P501
P260
P280
P303_361_353
P322
P362
Component Parts 1l Harz, 130ml Härter
Packing Unit Kit
Shipping Class
Hazardous Good LQ
Storage Temperature
RT
Weight 0.000000
Manufacturer
Struers
SDS (multilingual) ST1232-A, ST1232-B
