GO FIB Lift-Out Grids, 3, 4, 5, or 8 indexed Posts, Shallow Downset, Cu, 100 pieces

Like the Omniprobe models, the cost-effective copper lift-out grids have been specially developed for use in in-situ lift-out. They are available in versions with 3, 4, 5 and even 8 indexed pins. The diameter of all lift-out grids is 3 mm.
Grouped product items
Product Name Qty
GO FIB Lift-Out Grids, 3 indexed Posts, Shallow Downset, Cu, 100 pieces

PYGOFIB03C

€92.70 €110.31
GO FIB Lift-Out Grids, 4 indexed Posts, Shallow Downset, Cu, 100 pieces

PYGOFIB04C

€92.70 €110.31
GO FIB Lift-Out Grids, 5 indexed Posts, Shallow Downset, Cu, 100 pieces

PYGOFIB05C

€98.00 €116.62
GO FIB Lift-Out Grids, 8 indexed Posts, Shallow Downset, Cu, 100 pieces

PYGOFIB08C

€103.30 €122.93

Product Details

Description

3-Post Copper
End pins 180um wide, 200um length with 'V' shaped tip. Centre pin 80um wide, 200um length. 20um width shelf

4-Post Copper
End pins 180um wide, 200um length with 'V' shaped tip. Centre pins 80um wide, 200um length. 20um width shelf

5-Post Copper
All pins 60um wide, 200um length. 20um width shelf

8-Post Copper
All pins 60um wide, 200um length. 20um width shelf

Grid Thickness (All Versions)
3 & 4 Post nominally 35µm, 5 & 8 Post nominally 25µm

More Information

More Information
Grid Thickness 25µm, 35µm
Grid Size 3.0mm
Material
Copper
Packing Unit 100 Stück
Manufacturer
Graticules Optics
