ioLight - Portable Digital Fluorescence Microscope, 200x, 1mm field of view, 1µm high resolution

IOL-001-FL

The ioLight is now available as a fluorescent version. This microscope has fluorescence filters built in and so it is designed for fluorescence microscopy only. The filter behind the objective lens blocks blue light, so you will see green-yellow-red colours in the images from this microscope with white illumination only.

€2,585.00 €3,076.15

Product Details

Description

Viewing of fluorescent samples:

  • Great where bench space is limited
  • For samples >5-10um in size
  • Great for education, science outreach and demonstrations
  • In the lab the microscope is suitable for qualitative sorting of samples, eg sorting organisms that are successfully expressing GFP (or other fluorophores) from those that are not
  • Not suitable for quantitative fluorescence measurements



Specifications

Magnification 200x when viewed on 9” tablet screen. 1mm field of view
Excitation wavelength 465nm, other wavelengths on request
Emission wavelength >500nm (detection with a colour camera, so there is some discrimination of emission colour). Other emission wavelength options are available on request.
Brightfield Fluorescence only, not suitable for use in brightfield mode. Basic brightfield illumination is provided to help find subjects.
Display Smart phone, tablet, or computer with WiFi connection.
Direct connection, no WiFi infrastructure or router is required (internet is not required)
Image sharing On a smartphone or tablet, images and videos are stored in the gallery / camera roll for easy sharing.
On a computer, images and videos are stored in the web browser’s downloads folder.
ioLight App Free for download from the Apple® or Google Play® app store
Embedded web server connects to Google Chrome and most other browsers
Image format 5MP (2592 x 1944 pixels); colour
Video format MPEG-4; colour; up to 1296 x 972; 10 fps
Folded Dimensions 160mm x 101mm x 32mm
Operating Dimensions 160mm x 101mm x 107mm
Weight 450g
Power supply Integrated Li-ion rechargeable battery with USB charger (supplied)



Requirements
A tablet or phone running iOS 8.1 or higher or Android® 4.4 or higher, or a computer with WiFi and Google Chrome (or another web browser)
We recommend newer, faster devices. Older low-performance devices may work, but this is not guaranteed.



What’s in the box?

  • Your ioLight Magnificent Mobile Microscope
  • USB charger, international model
  • Protective pouch
  • Users’ guide and certificate of conformity





More Information

More Information
Packing Unit each
