ioLight - Portable Microscope with XY stage, 150x, 2mm field of view

IOL-0002-XY

As well as laboratory-grade resolution you can now take laboratory-grade precision with you. The patent-pending ioLight microscope with XY stage allows the user to move standard microscope slides or counting chambers along the X and Y axes in a perfectly straight line. Lab XY stages are big heavy chunks of metal but ioLight's stage is the thickness of a microscope slide and not much bigger. It even fits inside the standard field pouch dispatched with the microscope.

€1,550.00 €1,844.50

Product Details

Description

ioLight demonstration

Fokusing the ioLight microscope

Application

Veterinary Worm Egg Counting
Counting of algae and other samples
Easy positioning of the sample
Methodically scanning of slides and counting chambers
Works with standard microscope slides and counting chambers (25x75mm or 1”x2”) and with 32mm wide counting chambers
Allows manual movement of the slide and counting chamber independently in the left-right (X) axis and front-back (Y) axis

Specifications of microscop:

Magnification	150x (2mm microscope)
Resolution	1µm (1 micron = 1/1000mm) Similar to x20 objective and x10 eyepiece on conventional microscope)
Working Distance	2.5mm
Illumination	Adjustable top and bottom illumination (transmitted and incident light)
ioLight app*	Free for download from the Apple® or Google Play® app store;iOS 8.1 or Android 4.4 or higher, computer with WiFi (web browser)
Display	Smart phone, tablet or computer with WiFi; Direct connection, no WiFi infrastructure or router is required (internet is not required)
Sample Stage	Stainless steel
Image Sharing	On a smartphone or tablet, images and videos are stored in the gallery / camera roll for easy sharing. On a computer, images and videos are stored in the web browser’s downloads folder.
Image Format	5MP (2592 x 1944 pixels); JPEG; colour
Video Format	MPEG-4; colour; up to 1296 x 972; 10 fps
Operating Dimensions	160mm x 101mm x 107mm
Folded Dimensions	160mm x 101mm x 32mm
Weight	440g with neoprene case
Power Supply	Integrated Li-ion rechargeable battery USB charger (supplied)

Comparison of 1mm and 2mm versions

	1mm microscope	2mm microscope
Field of view (image width)	1mm	2mm
Magniofication	X400	X150
Resolution	1μm (1 micron = 1/1000mm) Ähnlich wie bei 20x-Objektiven und 10x-Okular von konventionellen Mikroskopen
Working distance (lens to sample)	1mm	2.5mm
Applications	Highest resolution portable microscope Cells – see more detail Applications where detail is required	Wider field of view, general purpose portable microscope Counting applications – see more cells Better for opaque samples like coins and engineering component inspection.
