Meltmount™ Quick-Stick™ with different refractive indexes

Cargille Meltmount™ Quick-Stick™ is a series of mounting media with different refractive index for use in microscope slide mounting and in other optical coupling applications. A direct replacement for old mounting mediums (Canada Balsam, Aroclor 5442, Naphrax...).
Grouped product items
Product Name Qty
Meltmount™ 1.539 Quick-Stick™

E17994-11

€191.20 €227.53
Meltmount™ 1.582 Quick-Stick™

E17994-31

€191.20 €227.53
Meltmount™ 1.605 Quick-Stick™

E17994-41

€191.20 €227.53
Meltmount™ 1.662 Quick-Stick™

E17994-51

€191.20 €227.53
Meltmount™ 1.680 Quick-Stick™

E17994-61

€191.20 €227.53
Meltmount™ 1.704 Quick-Stick™

E17994-71

€191.20 €227.53

Product Details

Description

Cargille Meltmount™ (optical quality) is a series of mounting media which are specifically formulated for use in microscope slide mounting and in other optical coupling applications. It is a direct replacement for old mounting mediums (Canada Balsam, Aroclor 5442, Naphrax...). Meltmount™ is also available in a Quick-Stick™ form which can be used to make permanent microscope slide mounts quickly. These Meltmount™ sticks can be applied to a slide on a hotplate. As soon as the specimen and coverglass are positioned and the slide is cooled you have a permanent prepared slide that can be reversed by reheating, if you should wish to retrieve a particular particle.

Features

  • Instant thermal mountants that require "no-oven-time".
  • 100% Usable; contains no solvents.
  • Reversible, thermally, for particle retrieval or re-orientation
  • Soluble in toluene for special techniques or clean-up.
  • Fluid at 65°C, a temperature chosen because it makes a permanent mount and protects the majority of specimens from thermal changes.
  • PCB-Free



Application

  • refractive index of 1.539 and an Abbe V dispersion of 45, optically similar to Canada Balsam therefore ideal for mounting biological specimens but without the long drying time of Canada Balsam
  • refractive index of 1.582 and an Abbe V dispersion of 33. Its optical clarity makes it the preferred choice for minimum visible absorption
  • refractive index of 1.605 and an Abbe V dispersion of 30, making it appropriate for mounting Asbestiform Tremolite, Anthophyllite, and Actinolite
  • refractive index of 1.662 and an Abbe V dispersion of 26, optically similar to Aroclor 5442 but is PCB-free
  • refractive index of 1.680 and an Abbe V dispersion of 25, making it appropriate for mounting Amosite and Crocidolite asbestos
  • refractive index of 1.704 and an Abbe V dispersion of 24, similar to Naphrax


Notes on use

  1. Meltmount™ is a Thermal Plastic Material. This means its viscosity is dependent on temperature, (inversely dependent). As the temperature increases the viscosity decreases. There is no sharp melting point. Being thermal plastic, it is capable of "cold flow". This means the Meltmount™, the specimen, the slide and the cover slip can all move independently of each other given a mix of time, temperature, and lateral pressure or gravity.
  2. Storage of prepared slides: treat them as the valuable items they are.


Store

  1. Flat, cover slip on top
  2. In the dark
  3. Away from dust and fumes
  4. At 60 to 85°F: Meltmount™ is meant to be thermally reversible, do not allow this to happen inadvertently by storing or transporting prepared slides above 85°F.



More Information

More Information
Mandatory sign
Tightly sealed goggles Tightly sealed goggles
Protective gloves Protective gloves
Signal word
Danger
Symbol GHS
GHS06 GHS06
GHS07 GHS07
Hazard statements
H302_H332
H315
H319
H330
H412
Precautionary statements
P264
P273
P280
P310
P321
P330
P362
P301_312
P305_351_338
P332_313
P333_313
P337_313
P405
Packing Unit 28g (Quick-Stick™, 18g)
Refractive Index Different refractive indexes
Suitable for Microscopy
Used for Fluorescence
no
SDS (multilingual) E17994-11, E17994-31
SDS (multilingual) E17994-41, E17994-51
SDS (multilingual) E17994-61, E17994-71
