Silver Conductive 18DB70X Adhesive, 15g

E12684-15

The acrylic Silver Conductive 18DB70X is a low VOC (Volatile Organic Compounds) coating suitable for EMI (Electromagnetic Interference) and RFI (Radiofrequency Interference) shielding protection. It is a direct substitute for the discontinued Silver Conductive Fluid 416.
€101.70 €121.02

Product Details

Description

The acrylic Silver Conductive Coating 18DB70X is a direct substitute for the discontinued Silver Conductive Fluid 416 that provides low resistances at very thin film thicknesses with excellent long-term shielding and grounding properties, also in harsh environments which makes it ideal for outdoor applications.

Key Properties

  • Conductive Protective Coating on Metals and Plastics
  • Excellent resistance to scratching and marring
  • High aging stability and shielding integrity
  • Recommended to mix with Acetone 1:1



Specifications

Pigment Silver
Binder Acrylic
Solid components Silver 50.8% ± 5%
Density 1.67kg/l

Low VOC

(Volatile Organic Compounds)

59.6g/l
Diluent Acetone (1:1 ratio by volume)
Drying time

Air dry 5min to touch and 10min to handle

Final Curing: 5min at 82° – 107°C or air cure for 24h

Sheet resistance: 0.015 ohms/sq/mil
Attenuation: 75 dB

More Information

More Information
Symbol GHS
GHS02 GHS02
GHS07 GHS07
Signal word
Danger
Mandatory sign
Tightly sealed goggles Tightly sealed goggles
Protective gloves Protective gloves
Hazard statements
H226
H260
H315
H317
H319
H336
H411
Precautionary statements
P210
P223
P303_361_353
P305_351_338
P405
P501
Storage Temperature
RT
Shipping Class
Hazardous Good LQ
Packing Unit 15g
SDS (multilingual) E12684-15
