Wafer-Mount™ 559

Wafer-Mount™ 559

Wafer-MountTM 559 temporary adhesive sheets (25,4cm x 25,4cm) are ideal for holding down silicon wafers, alumina, or glass substrates for scribing or dicing. Parts can be separated from the wafer-mount 559 film by washing in acetone or MEK

Grouped product items
Product Name Qty
Wafer-Mount™ 559, sheets, 2 pieces/pk

E50403-02

€77.40 €92.11
Wafer-Mount™ 559, sheets, 10 pieces/pk

E50403-10

€349.80 €416.26

Product Details

Description

To use, remove the paper backing exposing the adhesive layer. The substrate is positioned on the film and pressed down firmly so that it adheres to the plastic film. No heating is required. The wafer mounted on the plastic film can then be held down using a vacuum manifold or by mechanical means for dicing or scribing. After dicing or scribing, the parts can be separated from the wafer-mount 559 film by washing in acetone or MEK.



Table Crystalbond and Wafer-Mount

Name Crystalbond™ 509 Crystalbond™ 555 Crystalbond™ 590 Wafer-Mount™ 559 Wafer-Mount™ 562
Art. Nr. E50400-X E50401-X E50402-X E50403-X E50404-X
Description

Excellent adhesion to metals, glass, and ceramic

Transparent in thin cross sections.

Minimizes clogging of diamond tools.

Low melting point adhesive.

Soluble in hot water.

Good for low shear processes.

Transparent in thin cross sections.

Excellent adhesion for cutting sub-miniature parts

Slightly flexible.

Soluble in methanol or non hazardous 590-S stripper.

Semi-rigid solvent resistant plastic film with pressure sensitive soluble.

Ideal for scribing wafers with vacuum hold down.

Thermoplastic film adhesive

with good adhesion to metals, glass, and ceramic

excellent for mounting fragile thin substrates.
Form Stick Stick Stick Sheet Sheet
Dimension 2,2cm x17,8cm 1,3cm x 17,8cm x 2,5cm 1,6cm x 3,2cm x 19cm 0,12mm x 25,4cm x 25,4c 0.076mm x 20,3cm x 25,4c
Weight 90g/Stick or Bar 68g/Stick (or 68g/lump for Crystalbond TM555-HMP) 226g/Stick n/a n/a
Flow Point (C°) 121°C 54°C 150°C n/a 93°C
Viscosity, cps 6,000 500 9,000 n/a n/a
Color Clear yellow, amber/brown or turquoise white brown clear white
Solvent Acetone or MEK/509- Stripper“ (Art.Nr. E50040-S1/S2) Hot water Methanol or „590-S Stripper“ (Art. Nr. E50402-S) Acetone or MEK Trichloroethylene or Toluene

More Information

More Information
Dimensions 0,12mm x 25,4cm x 25,4cm
Flow Point (C°) n/a
Solvent Acetone or MEK
Viscosity n/a
Weight n/a
Color clear
SDS (multilingual) E50403-02/-10
