ZEISS Axioscope 5 - Microscope incl. Camer for Cytology and Cytopathology

The Axioscope product family has been optimized for use in specific application areas. You as the user are the focus and benefit from convenient operation and all relevant contrast methods for solving your microscopic tasks.

Convenient Operation, Efficient Workflow

• Ergonomic operating concept: To prevent hand strain, all important controls such as the focus drive, stage drive, light manager, and image capture button are located on both sides of the housing.
• Uncomplicated image capture: The easily accessible capture button makes digital image capture a breeze. With just one touch of a button, the image can be captured without having to lose control of the position, magnification, or contrast settings.

Specifications:

• Digital Multichannel Fluorescence
• Automated Light Manager
• Automated Objective Detection
• Image Capture Button on Microscope Body
• 4K-Camera with Ultra HD Resolution

Configuration:

Microscope stand Axioscope 5, TL, 6x H encoded, LED/HAL 100:

• Lower stand part with dovetail illumination interface
• Transmitted-light illumination with white LED 10W, optional for HAL12V 100W
• Dovetail mount for attachable stage carriers
• 24 mm focus lift, adjustable focus stop
• 6-position filter wheel for dia. 36 mm filters in TL
• Mount for 2-position filter slider 14x40, d=36 mm
• Integrated 24V DC 60W power unit, stabilized 100...240V AC/ 50...60Hz
• Country-specific power cable
• ECO mode and light management control button
• Snap button supports on ZEISS Axiocam
• USB 2.0 to PC
• Dust cover
• Filter holder in TL
• Upper stand part for transmitted light with nosepiece 6x H, M27
• Dovetail mount for changeable reflector turrets and reflector slider

Includes in addition:

• 2x Eyepiece PL 10x/23 Br. foc.
• 2x Eyepiece eyecup

Binocular ergophototube -2° to 28°/23 (50:50), reversed image:

• With tiltable range from -2° to 28°, field of view 23mm
• Split ratio between camera and eyepieces is 50:50
• Camera port with interface 60N
• Non-compatible with multidiscussion equipment

Stage Carrier and Condenser Carrier:

• Stage carrier D/A; attachable and vertically adjustable for Axioscope, to accommodate screw-on stages
• Condenser carrier with vertical adjustment on both sides for use with attachable Axio Scope stage carriers, adjustable height stop
• Mechanical stage 75x50 R with hardcoat anodized surface
• 220 x 150 mm stage plate
• Rackless X-guide positioned at bottom, hidden gear in Y-guide
• Right drive 135 mm (extendable by 15 mm), with friction setting
• Specimen holder for two slides 76x26mm, spring lever left

Condenser, achromatic-aplanatic 0.9 BF:

• With front lens which can be switched on the right and left
• For objectives 1.0x-100x, WD=1.0mm

Objectives:

• Objective N-Achroplan 5x/0.15 M27 (FWD=12.0mm)
• Objective EC Plan-Neofluar 10x/0.3 M27 (FWD=5.2mm)
• Objective EC Plan-Neofluar 40x/0.75 M27 (FWD=0.71mm),
• incl. Cover glasses, high performance, CG=0.17mm, box with 100 pc.

Microscopy Camera Axiocam 212 color Modul incl. Adapter 0,5x:

• Microscopy Camera Axiocam 212 color
• Camera Adapter 60N-C 2/3" 0,5x
• Most versatile color camera for education, documentation and routine applications with standalone capability, USB 3.0 and Ethernet connectivity with 64bit driver software for: ZEN (blue and core), Labscope and TWAIN plugin.


Here you will find further information about cytology and cytopathology.
