NIGHTSEA™ Add-On Light and Filter Set, with BNC-Connector
Product Details
Description
NIGHTSEA™ Add-On Light and Filter Set for the NIGHTSEA™ Stereo Microscope Fluorescence Adapter is available for various excitation/emission wavelengths. LED Light head and filters can be removed and replaced in seconds. A color coding ensures that you are using the right combination.
| Article-no. | Filter set | Excitation | Emission | Fluorophores |
| ESFA-BLFS-RB | RB- Royal Blue | 440-460 nm | 500 nm LP | EGFP, Fluorescin, Alexa488. ... |
| ESFA-BLFS-CY | CY - Cyan | 490-515 nm | 550 nm LP | YFP, Venus, Lucifer Yellow, ... |
| ESFA-BLFS-GR | GR - Green | 510-540 nm | 600 nm LP | DsRed, dTomato, Alexa568... |
| ESFA-BLFS-VI | VI - Violet | 400-415 nm | 460 nm LP | CFP, ... |
| ESFA-BLFS-UV | UV - Ultra Violet | 360-380 nm | 415 nm LP | DAPI, ... |
Please note: Light Head connectors come in two types. They are not interchangeable. The new style connector is called a BNC, and the original connector is a V1. There are two differences - the connector on the end of the gooseneck and the mating connector on the back of the light head. It is easy to tell them apart:
- The BNC connector on the gooseneck is silver, while the V1 connector is black.
- The BNC light heads have the letters BNC printed on the side.
More Information
| Type |
Illumination
|
|---|---|
| Packing Unit | set |
| Used with |
Stereo Microscopes
|
| Manufacturer |
NIGHTSEA
|
-
Starting at €1,920.90 €2,285.87
NIGHTSEA™'s new Stereo Microscope Fluorescence Adapter adds fluorescence to just about any stereo microscope (or dissecting microscope) with no modification to the microscope itself. The modular design lets you easily switch between several excitation / emission combinations to work with a variety of fluorescent proteins and other fluorophores.
The NIGHTSEA™ comes now with a BNC-connector.
Starting at €1,920.90 €2,285.87
-
€447.20 €532.17Art.Nr: ESFA-LH-WHA LED white light head is also available as an illumination option for the Stereo Microscope Fluorescence Adapter. Now if you are using the NIGHTSEA™ system for fluorescence you do not need a separate light source for your white-light work - just exchange the fluorescence excitation light head module for the white-light module in a matter of seconds. Extremely convenient for general illumination and as a focusing aid for fluorescence imaging. Comes with a BNC connector.€447.20 €532.17 -
Starting at
The NIGHTSEA™ light-head hangers and cables conveniently hold the light-head instead of the gooseneck lamp. The hangers mount to the thumbscrews on the SFA adapter ring. They are available with two different pivot arm lengths for use with long and short working distance microscopes.Starting at
