NIGHTSEA™ Stereo Microscope Fluorescence Adapter, with Filter

NIGHTSEA™ Stereo Microscope Fluorescence Adapter is a simple and inexpensive option to upgrade your standard bright-field stereo microscope to a fluorescence stereo microscope without any modifications. NIGHTSEA™ works with LED technology and is available for various excitation/emission wavelengths. A simple click-system makes it easy to change between filter-sets within seconds.

NIGHTSEA™ is available for following wavelengths:

With NIGHTSEA™ your stereo microscope is ready for plenty of new applications:

• Screening and sorting of transgenic lines by fluorescence – Drosophila, Zebrafish, C. elegans, Xenopus, Arabidopsis,...
• Fluorescence-aided dissection, injection, or micromanipulation
• Fluorescence for education – for laboratory courses and in the classroom
• Fluorescence-aided electronic circuit board repair

NIGHTSEA™ is modular and removable...

• A simple click-system installs NIGHTSEA™ within seconds
• Interchangeable excitation/emission combinations
• No modification to your microscope needed
• One set can be used at several microscopes

Economical — More Glow for the Dough...

• Stretch your lab budget
• Inexpensive enough for classroom use

Grows as your lab grows...

• Buy just what you need now (up to 5 different wavelength sets)
• Add more as your needs expand

NIGHTSEA™ Stereo Microscope Fluorescence Adapter system consists of:

• Flexible goose-neck lamp base with power supply
• LED Light head for excitation – available in various wavelengths
• Ring adapter to mount the barrier filter – fits up to 67mm standard lenses
• Barrier filter for emission – easy to attach by magnets
• Filter shield – for direct viewing

Once you are set up for one excitation/emission wavelength combination, additional combinations can be added by purchasing a kit that consists of LED light head, barrier filter, and filter shield.

Microscope Mounting Adapter - fits up to 67mm standard

Please note: Light Head connectors come in two types. They are not interchangeable. The new style connector is called a BNC, and the original connector is a V1. There are two differences - the connector on the end of the gooseneck and the mating connector on the back of the light head. It is easy to tell them apart:

• The BNC connector on the gooseneck is silver, while the V1 connector is black.
• The BNC light heads have the letters BNC printed on the side.
