TEM Grids, Formvar/Carbon Film coated, 2x1mm Slot, Ni

A formvar coated TEM grid, stabilized with evaporated carbon film. This type of coating is excellent for specimen support, especially for ultra thin sections. The thickness ranges from 5-50nm formvar and 1-30nm carbon. For detailed information see description.

Grouped product items
Product Name	Qty
TEM Grids, Formvar/Carbon Film coated, F 10nm / C 1nm, 2x1mm Slot, Ni, 25 pieces EFCF2010-Ni-25 €137.70 €163.86
TEM Grids, Formvar/Carbon Film coated, F 10nm / C 1nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-50 €220.70 €262.63
TEM Grids, Formvar/Carbon Film coated, F 5-6nm / C 20-30nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-UC
TEM Grids, Formvar/Carbon Film coated, F 5-6nm / C 3-4nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-UB
TEM Grids, Formvar/Carbon Film coated, F 5-6nm / C 1nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-UA €220.70 €262.63
TEM Grids, Formvar/Carbon Film coated, F 15-20nm / C 20-30nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-TC €222.40 €264.66
TEM Grids, Formvar/Carbon Film coated, F 15-20nm / C 3-4nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-TB €222.40 €264.66
TEM Grids, Formvar/Carbon Film coated, F 15-20nm / C 1nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-TA
TEM Grids, Formvar/Carbon Film coated, F 10nm / C 20-30nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-SC €220.70 €262.63
TEM Grids, Formvar/Carbon Film coated, F 10nm / C 3-4nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-SB €220.70 €262.63
TEM Grids, Formvar/Carbon Film coated, F 25-50nm / C 20-30nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-EC €226.00 €268.94
TEM Grids, Formvar/Carbon Film coated, F 25-50nm / C 3-4nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-EB
TEM Grids, Formvar/Carbon Film coated, F 25-50nm / C 1nm, 2x1mm Slot, Ni, 50 pieces EFCF2010-Ni-EA

Product Details

Description

Formvar/Carbon film thickness ranges:

	Option	Name	Formvar Film	Carbon Film
Standard	Option A	SA	10nm	1nm
Standard	Option B	SB	10nm	3-4nm
Standard	Option C	SC	10nm	20-30nm
Ultra-Thin	Option A	UA	5-6nm	1nm
Ultra-Thin	Option B	UB	5-6nm	3-4nm
Ultra-Thin	Option C	UC	5-6nm	20-30nm
Thick	Option A	TA	15-20nm	1nm
Thick	Option B	TB	15-20nm	3-4nm
Thick	Option C	TC	15-20nm	20-30nm
Extra Thick	Option A	EA	25-50nm	1nm
Extra Thick	Option B	EB	25-50nm	3-4nm
Extra Thick	Option C	EC	25-50nm	20-30nm

More Information

More Information
Coating	Formvar/Carbon
Grid Size	3,05mm
Hole Size	2x1mm
Hole/Slot Size	2000x1000µm
Material	Nickel
Material Symbol	Ni
Mesh Style	Slot
Manufacturer	EMS
