ZEISS, Stereozoom-Microscope Stemi 508
Product Details
Description
Stemi 508 allows observation and documentation of samples as they are: rich in detail, sharp in focus and free from color fringes. The large object field of 36mm helps keeping the overview of the samples. The 8:1 zoom enables the visualisation of small details and tiny structures with a magnification up to 50x, with interchangeable optics even up to 250x. Using interchangeable optics the area of observation can be enlarged to 122mm and a free working distance of 287mm. The modular system of Stemi 508 ranges from basic stands with reflected and transmitted illumination to overhanging tilt-arm stands for high mobility and large samples. The low viewing angle of 35° enables an ergonomic work posture for long working hours.
The illumination options range from integrated LED light to external fiber optic cold light source with various light guides and accessories for high brightness and special contrasts like polarization.
Specifications
Free Working distance |
92mm (basic), up to 287 mm (interchangeable optics) |
Working surface |
D195xW160 mm (basic) |
Comparative table
Model* |
Microscope body |
Stand |
Incident Illumination |
Attachment |
ZS508-0006 |
Binocular, 10x/23 Br. foc. |
K EDU with integrated LED transillumination for BF/DF |
Single-spot K LED |
|
ZS508-0007 |
Trinocular, 100vis/100doc right, Camera adapter C-Mount 2/3'' 0.5x |
K LAB, integrated LED transillumination with rotatable mirror for BF/DF or oblique transillumination |
Gooseneck double-spot K LED |
- |
ZS508-0008 |
Trinocular, 50vis:50doc right, Camera adapter C-Mount 2/3'' 0.5x |
K MAT w/o transillumination, ESD protection feature: antistatic surface |
Ring illuminator K LED, segmentable, 48 LEDs in 2 rows |
Front Optics 5 Apo 0.63x, FWD 127 mm |
ZS508-0023 |
Trinocular, 16x/14 Br. foc., 100vis/100doc right, Camera adapter C-Mount 2/3'' 0.5x |
M LED, Working surface W255xD215 mm; Transillumination Unit M LED, rotatable mirror (plain/diffuse) |
- |
Front Optics 5 Apo 1.5x, FWD 53 mm |
*other configurations on request
>>> Sales only within Germany! <<<
More Information
Type |
Stemi 508
|
---|---|
Eyepieces | PL 10x/23mm Br. foc, PL 16x/14mm Br. foc |
Head | 360° rotating, 35° viewing angle, interocular distance 55-75mm |
Illumination |
LED
|
Magnification | 6,3x-50x (basic version), 2x-250x (interchangeable optics) |
Manufacturer |
ZEISS
|
