ACLAR® Fluoropolymer-Film, 210x297mm (DIN A4), 51µm thick (2mil), 25 pieces

A50426-25

ACLAR® UltRx is a PCTFE homopolymer film. It offers an outstanding moisture barrier, excellent chemical resistance and minimal dimensional change (<2%). It is crystal clear, biochemically inert, plasticizer and stabilizer free. It is successfully used to grow cells, perform high-pressure-freezing (HPF) and for embedding.
€175.00 €208.25

Product Details

Description

ACLAR® is made from fluorinated-chlorinated resins. There are four basic film types–the homopolymer ACLAR® Rx Series, the new ACLAR® UltRx and the discontinued copolymers ACLAR® 22A and 33C (Honeywell). The chemical make-up of all ACLAR® products provide an exceptional moisture barrier. ACLAR® is crystal clear, biochemically inert, highly resistant to most chemicals and sterilizable by heat or radiation. ACLAR® is used widely in pharmaceutical, medical, sensitive electronics and military packaging.

ACLAR® UltRx is a PCTFE homopolymer film. It offers an outstanding moisture barrier, excellent chemical resistance and small dimensional change (<6%). It is crystal clear, biochemically inert, plasticizer and stabilizer free. It is successfully used to grow cells, perform high-pressure-freezing (HPF) and for embedding.

Features:

  • Crystal clear, high UV transparency– ideal for use in UV curing of embedding resin in microscopy.
  • Chemically stable and biochemical\y inert– the product of choice for growing cell cultures.
  • Low dielectric constant, high electric strength and dissipation factor– offers excellent cell attachment even through lengthy processing procedures.
  • Low surface energy–and separates easily from epoxy.
  • Exhibits no detectable autofluorescence– ideal for fluorescent microscopy.
  • A non-flammable, non-aging co-polymer–
    which is suited for sterilization by heat or UV.
  • Crystalline melting point is 211°C (403°F)– stable in the SEM.
  • Flexible and soft– can be sectioned without damage to the ultramicrotome knives.

ACLAR® film is now available in 2 mil (51µm) thickness and it is offered in DIN A4 (210x297mm) sheet form with package quantities of 10 or 25.



ACLAR® Physical Data Sheet

(These are typical values for 2.00mil PCTFE homopolymer and are not to be interpreted as product specifications):

Properties@ 73°F ~50% RH English Metric Test Method
Gravity Specific 2.11 ASTM D1505
Yield
6,567 in2/lb. 9.34m2/kg
Haze <1% ASTM D1003
Crystalline Melting Point 412°F 211°C ASTM D4591
Dimensional Stability, 10 min @ 300°F
-MD
-TD
<+6%
<6%
ASTM D1204
Water Vapor Transmission
Rate @ 100°F (37.8°C)/ 100% RH
0.0077 gm/100 in2/day 0.119 g/m2/day ASTM F1249
Flammability Nonflammable
Surface Tension
>42 dynes/cm
ASTD D2683



ACLAR® Chemical Resistance (typical)

Chemicals Average Weight Increase Visible Effect on Sample
Acetone 0.5% None
Butyl Alcohol - None
Carbon Tetrachloride 1.6% Slightly flexible
1,2-Dichloroethane 0.03% None
Ethyl Acetate 6.0% Very flexible
Ethyl Alcohol None None
Ethyl Ether 5.2% Very flexible
Ethylene Oxide 4.0% Very flexible
Formic Acid None None
Gasoline None None
All Acids (HCl, H2SO4..) None None
Methanol None None
Propylene Oxide - None
Toluene 1.1 Slightly flexible
Osmium Tetroxide None None
Plastisolve - None

More Information

More Information
Dimensions 210x297mm (DIN A4)
Packing Unit 25 pieces
Manufacturer
ACLAR
