C1, Disc Aperture for electron microscopes, D 1µm

PY04D00900

Material: Cu, Aperture Diameter: 1µm, Dimensions: 16mm / 3mm (Foil), filmthickness: 0,009mm
€178.10 €211.94

Product Details

Description

Pinholes - C Serie

Prepared in pure copper foil. Very high roundness edge definition. Blackened on one surface. Mounted in black anodized aluminium discs. Mounted in a recessed hole in an anodised holder.

Uses:

  • Spatial filtering
  • Controlling diameter of light beams
  • creating point light sources
  • image analysis etc.



Range                Tolerance

9µm                     +/- 0,3µm


Note: Dust particles can create noticeable aperture problems. Therefore store in dust free envelopes and, when necesassary, clean ultrasonically.



More Information

More Information
Manufacturer
Graticules Optics
Foil Thickness 9µm
Thickness
2,0mm
Packing Unit each
Material
Cu
Dimensions 16mm / 3mm (Foil)
Type
Disc Apertures
Aperture Diameter 1µm
Aperture Diameter
0-50µm
