Halcyonics_i4 - aktive Schwingungsisolationsplattform

Halcyonics_i4 - active vibration isolation platform

The active anti-vibration platform can easily be installed on stable tables or lab benches. The slim designed, fully automated platform is ready for use immediately without adjustment or fine adjustment and minimizes vibration frequencies above 1Hz.

Grouped product items
Product Name	Qty
Halcyonics_i4 - active vibration isolation platform, 400 x 500mm AC810038
Halcyonics_i4 - active vibration isolation platform with M6 tapped holes, 400 x 500mm AC810039
Halcyonics_i4 medium - active vibration isolation platform, 600 x 600mm AC810053
Halcyonics_i4 medium - active vibration isolation platform with M6 tapped holes, 600 x 600mm AC810057
Halcyonics_i4 large - active vibration isolation platform, 550 x 700m AC810046
Halcyonics_i4 large - active vibration isolation platform with M6 tapped holes, 550 x 700m AC810048

Product Details

Description

Key Features

Automatic load adjustment and transport lock
Multifunctional isolation system for a wide range of applications
Compact and portable
No natural low frequency resonance - excellent vibration isolation characteristics in low frequency range
Active isolation in six degrees of freedom
Excellent position stability - high inherent stiffness
No compressed air required - just power supply
Instantaneous generation of a counterforce to compensate vibrations — real active isolation

Specifications

	i4	i4_medium	i4_large
Dimensions	400 x 500x 90mm	600 x 600 x 90mm	550 x 700 x 92mm
Load capacity	0 - 120kg	0 - 105kg 40 - 150kg	0 - 105kg 40 - 150kg
Weight	20kg	37kg	40kg
Isolation technology	Halcyonics control technology based on piezoelectric type acceleration pickup, fast signal processing and electro-dynamic force transducers.
Force directions	Active compensation in all six degrees of freedom.
Isolation performance	> 5Hz = 25dB (94.4%) > 10Hz = 40dB (99.0%)
Active bandwidth	0.6 – 200Hz* (passive isolation beyond 200Hz)
Settling time	300ms**
Response time	0.5ms***
Stroke of the actuator	1mm
Max. correction forces	Vertical ± 8N Horizontal ± 4N
Max. compensation level	500µm/s at 6Hz and 60kg**
Repeatability of load adjustment	120µm
Table top material	Powder coated aluminum
Top plate surface flatness	± 0.10mm over complete surface
Environmental and operational requirements	Electrical voltage: 100 – 240V / 47 – 63Hz Power consumption: Typically 40 – 45W Operating temperature: 15 – 40°C Relative humidity: 0 – 60% Operating altitude: < 2,500m
Electrical safety	CE certified according to directive 2006/95/EC
EMC	CE certified according to directive 2004/108/EC

* The low-pass characteristics of the spring-mass combination dominate the dynamic behavior of the isolation system above 200Hz. The part of the active isolation decreases with increasing frequency.

** The settling time and maximum compensation level depend on several conditions such as payload, frequency and load distribution. The mentioned settling time value is exemplary for a centric load of 80kg. The settling time defines the time until an incoming vibration is compensated.

*** The response time determines when the system starts to actively isolate an incoming vibration after detection by the sensors.

For detailed information see data sheet.
