L100, Slit Aperture for electron microscopes, 100x2000µm

PY04D00955

Material: Cu, Rectangular Slit: 100x2000µm, Dimensions: 16mm / 3mm (Foil), Thickness: 0,025mm
€172.38 €148.60

Product Details

Description


Mounted Slits - L Serie

Spectrophotometer entrance and exit slits. Imaging and alignment applications suitable for complete UV - IR frequency range.

Manufactured by a process that produces ultra high edge definition, shape and size. The metal profile is such that the minimun dimension of the aperture is within a micron of one face.

Aperture sizes are measured at up to 1000x magnification and the tolerance below apply to the width throughout the length.

Each slit is centered in a copper foil disc, 15-25 microns thick, mounted in a recessed hole in an anodised aluminium holder.


Range               Tolerance

26 - 100µm      +/-0,5µm


More Information

More Information
Foil Thickness 15-25µm
Dimensions 16mm / 3mm (Foil)
Thickness
0,025mm
Packing Unit each
Material
Cu
Manufacturer
Graticules Optics
Type
Slit Apertures
Aperture Diameter 100x2000µm
