L250, Slit Aperture for electron microscopes, 250x2000µm

PY04D00956

Material: Cu, Rectangular Slit: 250x2000µm, Dimensions: 16mm / 3mm (Foil), Thickness: 0,025mm
€148.60 €176.83

Product Details

Description


Mounted Slits - L Serie

Spectrophotometer entrance and exit slits. Imaging and alignment applications suitable for complete UV - IR frequency range.

Manufactured by a process that produces ultra high edge definition, shape and size. The metal profile is such that the minimun dimension of the aperture is within a micron of one face.

Aperture sizes are measured at up to 1000x magnification and the tolerance below apply to the width throughout the length.

Each slit is centered in a copper foil disc, 15-25 microns thick, mounted in a recessed hole in an anodised aluminium holder.


Range               Tolerance

101 - 500µm    +/-0,5µm


More Information

More Information
Manufacturer
Graticules Optics
Foil Thickness 15-25µm
Thickness
0,025mm
Packing Unit each
Material
Cu
Dimensions 16mm / 3mm (Foil)
Type
Slit Apertures
Aperture Diameter 250x2000µm
