LG25, Optical Slit Aperture, Chrome on Glass, 25x10.000µm

PY04B01002

Material: Chrome/Glass, Rectangular Slit: 25x10000µm, Dimensions: 16mm (Foil)
€295.49 €351.63

Product Details

Description

Key Features

Opaque chrome on B270 Glass Clear Slit 10µm wide by 10mm long

 Description

Chrome optical density +4.0

16mm Diameter B270 Crown Glass substrate

Photo-etched in chrome on optical glass. Spectrophotometer entrance and exit slits. Imaging and alignment applications. Allows use of longer slits then air type. Some transmission frequency limitations imposed by substrate.

Note: The efficiency of such fine apertures can be noticeably affected by dust particles. They should be stored in dust free envelopes and, when necessary, cleaned ultrasonically.

More Information

More Information
Type
Slit Apertures
Dimensions 16mm (Foil)
Material
Chrome/Glass
Packing Unit each
Manufacturer
Graticules Optics
