Sample Stub Vacuum Desiccator

BI76550

Precision machined from a block of aluminum – anodized black - this Sample Stub Vacuum Desiccators accommodates 18 SEM Mounted Sample Stubs, pin style, under vacuum for long time. Measures: 13x13cmx4,5cm. Chamber cavity is 10,4cm diameter x 18mm deep. Lid is made with 10mm thick clear acrylic.

€550.00 €654.50

Product Details

Description

Mini desiccator

This model is particularly suitable as dust and oxidation protection for organic and inorganic samples, but also for storing calibration samples. The desiccator has a conical suction nozzle that can be removed after evacuation. Unintentional ventilation is therefore impossible. This makes it ideal for transporting samples when traveling, for example. The evacuated volume allows 19 grid samples (3mm pin, standard Zeiss/FEI/Philips) or grid boxes for transmission electron microscopy to be accommodated.

Technical data

External dimensions: 130mm x 130mm x 46,5mm
Total height without cover: 40mm
Sample chamber inner diameter: 104mm
Sample chamber height: 18mm
Vacuum: Yes
Nitrogen storage: Yes
Intert gas storage: Yes
Transport of grid boxes: Yes
Transport of SEM samples: Yes
