TEM Grids, Graphene on Ultra-Fine 2000 Mesh, various Layers, Cu
Graphene film of various thickness, on a ultrafine 2000 mesh copper TEM Grid without additional support film. The TEM Grids are available with graphene film of 1, 2, 3-5 to 6-8 layers. Ideal for nanoparticle analyses.
Product Details
Description
Thin mono layers of graphene are created by using the process of chemical vapour deposition.
Characteristics
- Four thicknesses of graphene available: 1, 2, 3-5 or 6-8 layers
- Substrate is a microporous (2000 mesh) copper TEM grid with Beryllium-Copper support aperture
- Graphene coverage of the TEM grid more than 75%
Appearance
The graphene film is near-transparent to light-grey film depending on the number of layers and sit on the red-brown coloured Copper TEM grid. The TEM grid is supported by a gold coloured Beryllium-Copper disk with 2x1mm aperture epoxy-glued to the grid.
Specifications
| Type | Thickness of the Graphene |
Transparency | TEM Grid/AFM Substrate | Support Film |
| 1 Layer | ~ 0,35nm | ~96,4% | ultrafine 2000 Mesh Copper | N/A |
| 2 Layer | ~ 0,7nm | ~92,7% | ultrafine 2000 Mesh Copper | N/A |
| 3-5 Layer | 1,0 - 1,7nm | ~85,8-90,4% | ultrafine 2000 Mesh Copper | N/A |
| 6-8 Layer | 2,1 - 2,8nm | ~78,5-83,2% | ultrafine 2000 Mesh Copper | N/A |
CAS No. 7782-45-5
More Information
| Coating |
Graphene
|
|---|---|
| Film Thickness | 0,35 - 2,8nm |
| Material |
Copper
|
| Material Symbol | Cu |
| Mesh Size |
2000 Mesh
|
| Mesh Style |
square
|
| Manufacturer |
EMS
|
