ZEISS Primovert with Stand-Alone-Camera

Daily life in the cell lab consists of many cycles: opening the incubator, placing cells under the microscope, checking them, and putting them back—often also preparing and counting cells. When you spend the whole day working with cell cultures, time is your most valuable resource.

The Zeiss Primovert was designed precisely for this: it is the microscope that doesn’t get in your way, but actively supports your workflow—right when you need it.

Why the Primovert fits into your lab routine:

• Ready to use immediately: No long warm-up times or complicated setup. The Primovert is ready to go as soon as you are.
• Compact design: It fits easily into any corner of your cell lab. You save the trip to the “big” microscope in the next room.
• Proven ZEISS optics: You don’t have to compromise on image quality. Even during routine checks, you see exactly what you need to—clear, high-contrast, and in the best ZEISS quality.
• Ergonomic work: Whether you just want to take a quick look or focus for longer periods, the ergonomic design reduces strain so your neck doesn’t ache at the end of the day.

Assess living cells—quickly and efficiently.

• Inspect and evaluate the morphology and development of living cells.
• With your Primovert, you can examine unstained cells in phase contrast and GFP-labeled cells in fluorescence contrast quickly and efficiently.
• The inverted microscope is perfectly suited for your cell culture lab. The Primovert is compact and fits directly into your laminar flow hood.
• Bring flexibility to your cell culture lab: with Primovert and the integrated camera, as well as the iPad Imaging App Labscope, you can observe your cells at any time, independent of the sterile workspace, and evaluate them together with your colleagues.

Specifications - Primovert mit binocular Phototubus

• Condensor 0,4 for Primovert
• Objectives: Plan-Achromat 4x/0,10 Ph0 / Plan-Achromat 10x/0,25 Ph1 / LD Plan-Achromat 20x/0,30 Ph2 / LD Plan-Achromat 40x/0,50 Ph2
• Ringaperture: Ph 0/0,4 Primovert / Ph 1/0,4 Primo Vert / Ph 2/0,4 Primo Vert
• Schieber Ph, 3-fach für Primovert
• LED Illumination
• Objektführer rechts für Primovert
• Halterahmen M für Mikrotiterplatten 96
• Halterahmen für Petrischalen d=54 mm und Objektträger 76x26
• Camera Axiocam 212 color
• Camera adapter P95-C 1/2" 0,5x
• BA Primovert EN

The Primovert product family:

• Primovert (base model): The standard model is designed for durability and efficiency. It is ideal for quick routine checks of living cells—easy to use and requiring little maintenance.
• Primovert photo: This version features a trinocular photo tube, giving you the flexibility to connect an external camera to document your cell cultures, save images for presentations, or perform analyses.
• Primovert ergo: Here, comfort is key. The adjustable viewing height and angle allow the microscope to be individually adapted to the user’s body size. This is especially valuable for supporting an ergonomic posture during long days in the lab and preventing neck strain.
• Primovert iLED: This model is designed for fluorescence applications. It is equipped with an LED fluorescence system, enabling quick and efficient examination of labeled samples without the need for complex fluorescence setups.
• Primovert HDcam: The “all-in-one” solution. This model comes with a built-in HD camera. You can view live images directly on a monitor, PC, or laptop without having to mount or configure an external camera—perfect for group work or quick digital documentation.

Expand your possibilities

With the Labscope software, you transform your ZEISS Primovert with camera or integrated HD camera into a WiFi-enabled imaging system. Whether in the lab or at university—Labscope captures images and records videos of your microscopic samples more easily than ever before. You can create annotations and reports, process images, and save files to your Windows network or simply share them with colleagues. Wherever you want. The intuitive user interface enables immediate use and minimizes training time.

Use with iPad

Use without iPad
