Thin Film Holder

Ideal for examination cross section of thin samples, such as wafers, multi-layer of capacitors, plastics, metals, etc. For most AMRAY: 12,7mm diameter , 3.1mm dia. pin 3.1mm with split openings up to 6.4mm. Pin height: 8mm, 15mm.

Grouped product items
Product Name	Qty
Thin Film Holder, 8mm (L) Pin E75948-08 €107.20 €127.57
Thin Film Holder, 15mm (L) Pin E75948-15 €139.00 €165.41
Thin Film Holder, 15x10mm Stub E75948-10 €116.20 €138.28

Product Details

Description

Ideal for examination cross section of thin samples, such as wafers, multi-layer of capacitors, plastics, metals, etc.

For most AMRAY: ½" diameter (12.7mm), 1/8" (3.1mm)dia. pin (3.1mm) with split openings up to ¼" (6.4mm). Available with either 8mm (5/16") pin height or 15mm (9/16") pin height.
For ISI, JEOL, TOPCON: Double set screw for a secure holding of the specimen during observation. 15mm(9/16")(dia). x 10mm(3/8")(H), 6.4mm(1/4") split.
