Size Standards

These fine mesh grids are suitable for the low magnification range of a TEM. Available as a sandwich in a folding 3.05mm mesh grid.

0,01mm grid / 1,5 x 1,5mm overall.

0,01mm grid / 0,2 x 0,2mm overall.

Counting Slide 0,05mm squares.

Counting Slide 0,1mm squares.

This ideal standard provides accurate calibration of any eyepiece, reticules, filar micrometers, or electronic measuring instrument. Useful for calibration range from 1X to 1000X power.

This ideal standard provides accurate calibration of any eyepiece, reticules, filar micrometers, or electronic measuring instrument. Useful for calibration range from 1X to 1000X power.

This standard can be used to test not only the overall frame distortion issue, but also linear distances for a wide variety of magnification ranges from 1x to 1000x power.

This standard can be used to test not only the overall frame distortion issue, but also linear distances for a wide variety of magnification ranges from 1x to 1000x power.

A dual axis linear micrometer that can accurately calibrate X & Y directions without rotation, for optical magnification, and camera aspect ratio using single standard.

A dual axis linear micrometer that can accurately calibrate X & Y directions without rotation, for optical magnification, and camera aspect ratio using single standard.

The IAM-MET is a multi-morphology calibration standard designed for ASTM. Includes all plates as found in IAM-1 except for plate 4. This plate contains 9 images of irregular shapes, simulating features commonly found in metallurgical applications.

Vision Calibration Standard, includes a set of eight test plates of various shapes, positions, angles and Sizes. It also includes a linear measurement scale for calibrating your imaging system. Overall Size: 25x75mm.

Vision Calibration Standard, includes a set of eight test plates of various shapes, positions, angles and Sizes. It also includes a linear measurement scale for calibrating your imaging system. Overall Size: 25x75mm.

Glass Size: 25x75mm. Scale Length: 0,08 inch (English) X & Y axis, 2.0mm (Metric) X & Y axis. Teilung: English = 0,001”, Metric = 25µm (0,025 mm). No numerical scale labeling.

Glass Size: 25x75mm. Scale Length: 0,08 inch (English) X & Y axis, 2.0mm (Metric) X & Y axis. Teilung: English = 0,001”, Metric = 25µm (0,025 mm). No numerical scale labeling.

Glass Size: 25x75mm. Scale Length: 0,08 inch (English) X-axis only, 2.0mm (Metric) X-axis only. Teilung: English = 0,001”, Metric = 25µm (0,025 mm). No numerical scale labeling.

Glass Size: 25x75mm. Scale Length: 0,08 inch (English) X-axis only, 2.0mm (Metric) X-axis only. Teilung: English = 0,001”, Metric = 25µm (0,025 mm). No numerical scale labeling.

Glass Size: 38x75mm. Scale Length: 1 inch (English) X & Y axis, 25mm (Metric) X & Y axis. Teilung: English = 0,0005”, Metric = 10µm (0,010 mm). With numerical labeling every 0,1 mm and 0,05”.

Glass Size: 38x75mm. Scale Length: 1 inch (English) X & Y axis, 25mm (Metric) X & Y axis. Teilung: English = 0,0005”, Metric = 10µm (0,010 mm). With numerical labeling every 0,1 mm and 0,05”.

Glass Size: 38x75mm. Scale Length: 1 inch (English) X & Y axis, 25mm (Metric) X & Y axis. Teilung: English = 0,001”, Metric = 25µm (0,025 mm). With numerical labeling every 1 mm and 0,1”.

Glass Size: 38x75mm. Scale Length: 1 inch (English) X & Y axis, 25mm (Metric) X & Y axis. Teilung: English = 0,001”, Metric = 25µm (0,025 mm). With numerical labeling every 1 mm and 0,1”.

Glass Size: 25x75mm. Scale Length: 1 inch (English) X-axis only, 25mm (Metric) X-axis only. Teilung: English = 0,0005”, Metric = 10µm (0,010 mm). With numerical labeling every 0,1 mm and 0,05”.

Glass Size: 25x75mm. Scale Length: 1 inch (English) X-axis only, 25mm (Metric) X-axis only. Teilung: English = 0,0005”, Metric = 10µm (0,010 mm). With numerical labeling every 0,1 mm and 0,05”.

Glass Size: 25x75mm. Scale Length: 0,04 inch (English) X & Y axis, 10mm (Metric) X &Y axis. Teilung: English = 0,01”, Metric = 100µm (0,1mm). English = 0,0005”, Metric = 10µm (0,010mm). With numerical labeling every 0,1 mm and 0,05”.

Glass Size: 25x75mm. Scale Length: 0,04 inch (English) X & Y axis, 10mm (Metric) X &Y axis. Teilung: English = 0,01”, Metric = 100µm (0,1mm). English = 0,0005”, Metric = 10µm (0,010mm). With numerical labeling every 0,1 mm and 0,05”.

Glass Size: 50x132mm. Scale Length: 5 inch (English) X-axis only, 125mm (Metric) X-axis only. Teilung: English = 0,01”, Metric = 100µm (0,1mm). With numerical labeling every 1 mm and 0,1”.

Glass Size: 50x132mm. Scale Length: 5 inch (English) X-axis only, 125mm (Metric) X-axis only. Teilung: English = 0,01”, Metric = 100µm (0,1mm). With numerical labeling every 1 mm and 0,1”.
