Triax™ Flow Cell (FC-3)

BFC-3

FC-3 is used for three wavelength scans, one or two for UV scans and the other one or two for the VIS scans. Up to three wavelengths can be recorded simultaneously in the same gradient. All three LEDs are driven and tuned simultaneously by using the Triax™ software.

Product Details

Description

Characteristics

UV and VIS measuring cell
Up to three wavelengths can be measured simultaneously
Software updates via drop box

Technical Specifications

Resolution: 1,040,000 units
Automatically AUFS setting
Flow cell: 2 x 2mm², 30µl
UV-wavelength: 260nm, 280nm
Fluorophores: EGFP, mCherry, AlexaFluor 488, AlexaFluor 555,
AlexaFluor 568, Cy2, Cy3, Cy5 and more on request
PC requirements: Win10, 2x USB-Port

Included

Triax™ Flow Cell
Triax™ Software
Set of LED, Ex. filter, Em. filters
USB cable PC to Triax^TM
USB cable PC to Frac
Connecting cables for fraction collector
Assorted Cap & Set Screws
IDEX Direct Injection Fitting w/20g needle
IDEX Input Fitting & Ferrule
20 cm Alignment Extensions
Flow Cell Cleaners
Manual (English)

Technical Data

Voltage	via USB (CE certified)
Dimensions	139,0mm x 62,0mm x 89,0mm (W/D/H)
Weight	5,9kg
