Vibrating Microtome 7000smz-2
E7000smz-2
The 7000smz-2 is a high precision vibrating microtome and provides finest tissue slicing for preparations for visual patch clamping or high-resolution imaging. With a Z-axis deflection of less than 1µm across a wide range of vibration speeds and amplitudes, the tissue slicer delivers healthy viable sections of all biological tissues. The 7000smz-2 represents an advanced high precision microtome and is supplied with its own Z-axis calibration verifier.
Product Details
Description
Features
- Includes a Z-axis calibration unit
- Minimal Z-axis deflection (less than 1µm) at all speeds and amplitudes
- Z-axis blade adjust minimizer
- Blade holder angle to user requirement
- Set start and stop position of blade travel
- Tissue sample automatically retracted before blade returns to start point
- Full range of adjustable parameters with 8 customizable user profiles
- Vibration speeds from 50 to 120Hz
- Amplitudes from 0.5mm to 2.5mm
- Controlled blade advance at 10µm per sec
- "Auto" programming by storage of the first slicing
- Ice water bath easily removed for cleaning
- Optional LED light and scope for clear observation
- Leaf spring vibratory mechanism for optimal longevity and accuracy
Specifications
| Optimal Z-Axis Deflection |
Sub-µm (±0.1µm) |
|
Opti-cal Vertical (Z-axis) Calibration Device |
Included as standard |
|
Blade Oscillation Frequency Range |
50-120Hz |
|
Frequency step size |
5Hz |
|
Blade Oscillation Amplitude |
Min: 0.5mm |
|
Amplitude Step Size |
0.25mm |
|
Advance Speed Resolution During Slicing |
0.01mm/sec |
|
Cutting head advance speed: |
Min: -4.0mm/sec (-1.00mm during slicing) |
|
Bath table rise & fall speed |
Max. 1.0mm/sec |
|
Specimen Retraction as Blade Retracts |
Yes |
|
Section thickness step size |
1µm |
|
Max. (vertical) travel of bath table |
19mm |
|
Max. travel of cutting head |
40mm |
|
Max. Specimen Size |
33 x 50 x 19mm |
|
Memory to Store Section Thickness |
Yes |
|
Multiple User Settings |
8 different |
|
Operating Modes |
Manual, semi-automated Slice Window or fully automated Profile Repeat |
|
Cooling Options |
Ice bath or optional Model 7610A Tissue Bath Cooler |
|
Dimensions |
16.5" x 15.7" x 10.6" |
