Vibrating Microtomes 5100mz-Plus
E5100MZ-Plus
The 5100-Plus is perfect for those who need to keep slices viable for longer, e.g. for electrophysiological field recordings. The user can calibrate the Z-axis deflection of the blade to 2µm with the adjustable blade holder and "optical" calibration device. Minimal Z-axis deflection reduces the "chatter" and minimizes damage to the slice surface, leading to greater viability of the cells on the slice surface.
Product Details
Description
Features
- Includes a z-axis calibration unit
- Vibration speeds from 50 to 80Hz
- Amplitudes from 0.5mm to 1.5mm
- Fine control of the blade advance (min. 0.1mm/sec)
- Set start and stop position of blade travel
- Remote controls allowing for sterile use in culture hood
- Ice water bath easily removed for cleaning
- Optional cold light and magnifier for clear observation
- Optional Peltier cooled bath
Specifications
Optimal Z-Axis Deflection |
2.0µm (±0.1µm) |
Opti-cal Vertical (Z-axis) Calibration Device |
Included as standard |
Blade Oscillation Frequency Range |
50-80Hz |
Frequency step size |
5Hz |
Blade Oscillation Amplitude |
Minimum: 0.5mm |
Amplitude Step Size |
0.5mm |
Advance Speed Resolution During Slicing |
0.1mm/sec |
Cutting head advance speed: |
Min: -2.0mm/sec (-1.00mm during slicing) |
Bath table rise & fall speed |
Max. 1.0mm/sec |
Specimen Retraction as Blade Retracts |
Yes |
Section thickness step size |
1µm |
Max. (vertical) travel of bath table |
19mm |
Max. travel of cutting head |
40mm |
Max Specimen Size |
33 x 50 x 19mm |
Memory to Store Section Thickness |
Yes |
Multiple User Settings |
8 different |
Operating Modes |
Manual or semi-automated Slice Window |
Cooling Options |
Ice bath or optional Model 7610A Tissue Bath Cooler |
Dimensions |
13.7" x 17.7 x 13.7" |
More Information
Packing Unit | each |
---|
