TRIAX™ Flow Cell (FC-1)

Triax™ Flow Cell (FC-1)

BFC-1

C-1 is the single wavelength version. The flow cell can be configured to record UV or fluorescence, allowing overlay of separate UV and VIS scans. Wavelength and fluorophore changes are made by changing the LEDs, photodiodes and filters.

Product Details

Description

Characteristics

  • UV or VIS measuring cell
  • One wavelength can be measured
  • Software updates via drop box


Technical Specifications

  • Resolution: 1,040,000 units
  • Automatically AUFS setting
  • Flow cell: 2 x 2mm², 30µl
  • UV-wavelength: 260nm, 280nm
  • Fluorophores: EGFP, mCherry, AlexaFluor 488, AlexaFluor 555,
  • AlexaFluor 568, Cy2, Cy3, Cy5 and more on request
  • PC requirements: Win10, 2x USB-Port


Included

  • Triax™ Flow Cell
  • Triax™ Software
  • Set of LED, Ex. filter, Em. filters
  • USB cable PC to TriaxTM
  • USB cable PC to Frac
  • Connecting cables for fraction collector
  • Assorted Cap & Set Screws
  • IDEX Direct Injection Fitting w/20g needle
  • IDEX Input Fitting & Ferrule
  • 20 cm Alignement Extension
  • Flow Cell Cleaner
  • Manual (English)



Technical Data

Voltage via USB (CE certified)
Dimensions 139,0mm x 62,0mm x 89,0mm (W/D/H)
Weight 5,9kg
