Triax™ Flow Cell (FC-2)

BFC-2

FC-2 allows two input wavelengths so the UV and VIS scans are obtained in the same gradient. Another use is the dual UV scan at 260 and 280 nm, providing a 260/280 ratio that reflects the change in nucleotide/protein composition of a particle.

Product Details

Description

Characteristics

  • UV and VIS measuring cell or as double UV measuring cell
  • Up to two wavelengths can be measured simultaneously
  • Software updates via drop box


Technical Specifications

  • Resolution: 1,040,000 units
  • Automatically AUFS setting
  • Flow cell: 2 x 2mm², 30µl
  • UV-wavelength: 260nm, 280nm
  • Fluorophores: EGFP, mCherry, AlexaFluor 488, AlexaFluor 555,
  • AlexaFluor 568, Cy2, Cy3, Cy5 and more on request
  • PC requirements: Win10, 2x USB-Port


Included

  • Triax™ Flow Cell
  • Triax™ Software
  • Set of LED, Ex. filter, Em. filters
  • USB cable PC to TriaxTM
  • USB cable PC to Frac
  • Connecting cables for fraction collector
  • Assorted Cap & Set Screws
  • IDEX Direct Injection Fitting w/20g needle
  • IDEX Input Fitting & Ferrule
  • 20 cm Alignment Extensions
  • Flow Cell Cleaners
  • Manual (English)




Technical Data

Voltage via USB (CE certified)
Dimensions 139,0mm x 62,0mm x 89,0mm (W/D/H)
Weight 5,9kg
